產品參數:
□ 額定電壓 Rated Voltage:1000 V DC
□ 額定電流 Rated Current:20-80A
□ 絕緣電阻 Insulation Resistance:≥500MΩ
□ 耐電壓 Withstand Voltage:3500V AC
□ 機械壽命Mechanical Lifetime:≥10000 cycles (no-load)
□ 插拔力 Insertion and Separation Forces:F<140N
□ 防護等級Protection Degree:IP55
□ 環境溫度 Operating Temperature:-30℃~50℃
□ 阻燃等級 Flame Retardant Grade:Ul94 V-0
□ 鎖止機構類型Type of Locking Mechanism:馬達鎖 electric motor
